nRF52832-MS50SFB1

Bluetooth 5.4 Low Energy Module

State-of-the-art Bluetooth 5.4 module-MS50SFB1 based on Nordic nRF52832 withfull GPIO and ultra-small size over the overall market. nRF52832 Module includes amultiprotocol 2.4GHz radio, 192kB Flash memory and 24kB RAM, has optimized 4dBm TX power and the best RX sensitivity of all SoCs in the nRF52 Series, which isan excellent choice for the cost-constrained project.


Specifications
Specifications
nRF52832-MS50SFB1Basic Parameters

Model NO.

MS50SFB1

Sensitivity(RX)

-96dBm

Antenna

PCB

Transmission Power

-40-+4dBm

SoCset

Nordic

   nRF52832


Current(TX)

0dBm-5.3mA/

Max Range

80M

Current(RX)

5.4mA

Dimension(mm)

20x12x2mm

GPIO

30

Flash

512kB

Certification

RoHS, REACH,CE, FCC, BQB, IC, SRRC, TELEC, WPC, RCM, WEEE, AEC, KC

RAM

64kB

Hardware

 Pass-through

Application



Security warning devices, smart meters, building automation, agricultural sensors, smart cities, retail store sensors, street lighting, environmental sensors, smart parking, smart medical



Download
Download
nRF52832-MS50SFB_Datasheet_K
Last Update Time  2024-09-29
File Size  2.11MB
Download Times  9
