Design sketch
Dual-Band Coverage
Supports dual-frequency operation for broader compatibility across wireless applications.
Stable Signal Performance
Omnidirectional radiation with vertical polarization ensures uniform coverage and reliable connectivity.
High Gain & Efficiency
Up to 5.33 dBi gain with peak efficiency of 73.11% for enhanced transmission performance.
Wide Temperature Range
Operates reliably from -30°C to +80°C, suitable for various environments.
Durable & Reliable
Passed vibration and drop tests for stable long-term use.
RoHS Compliant
Meets RoHS 2015/863/EU environmental standards.
Electrical Specifications | |
Frequency Range | 2400~2500MHz/5000~5800MHz |
VSWR | ≤2.5 |
GAIN | ≤5.33dBi |
Radiation | OMNI |
Polarization | LINEAR |
Input Impedance | 50 Ω |
Mechanical Specifications | |
Input connector | SMA-J |
Antenna material | ABS + COPPER |
Working Temperature | -30℃~+80℃ |
Working Humidity | 40~85% |
Weight | 17±1g |
